Industrial Temperature Sensor with 1.5 m long sensor cable [SI-T-02/SC]

Industrial Temperature Sensor with 1.5 m long sensor cable [SI-T-02/SC]

Product Code: SI-T-02/SC
Availability: Pre-Order
  • 99.00€


The IQ Home single Li-Ion Battery powered sensor family is developed for our automated measuring and data collectingsolution.

Key features:

  • Low power ISM frequency based wireless sensor
  • Ready to use IQRF - DPA compatible device
  • Single 3.6V Li-Ion Battery supply
  • More than 3 year batter life*
  • Easy to use communication protocol
  • Data collection from devices in one RF command ( Up to 62 devices with on RF command )

*Battery life is depend of measurement frequency, sleep period time, RF network size, RF network topology, operation temperature.

Package contains:

  • SI-T-02/SC Industrial Temperature Sensor with 1.5 m long sensor cable
  • 3.6V Li-Ion Battery ( included )
Temperature sensing
-40 °C to +85 °C / -40 °C to +125 °C (with external probe)
±0.3 °C (typical)
0.0625 °C
1.5m
RF Specifiaction
IQRF - DPA
DCTR-76D(A)
4.02D
3.02
Low Power
868 MHz (916 MHz on special request)
8 mW
Internal, PCB
Local display and control
LED (Red/Green) located inside
Environmental conditions
-40 °C to +85 °C
-40 °C to +85 °C
0 % to 100 %
Electrical specification
2400 mAh 3.6V Li-Ion Battery (AA size) [Battery included]
<1 uA (typical)
345 uA (typical)
Maximum 22 mA (according to RF output power)
< 2s
Mechanical and enclosure specification
Box 65mm(W) x 65mm(D) x 40mm(H)
Wall mountable
120 g
Light gray
IP65

There are no reviews for this product.

Write a review

Please login or register to review
Documentation
Product Briefs
Document Version Format Date
Sensor Brief [SI-xxx-02] 1.0.0 PDF 2019-04-12
Sensor
Document Version Format Date
Protocol Documentation [Sx-xxx-02] 2.0.2 PDFHTML 2018-10-25
Sensor Family Datasheet [SI-xxx-02] 1.0.0 PDFHTML 2018-09-26
