Product Code: GW-IND-01-ETH
Availability: Pre-Order
  • 329.00€


The IQ Home gateway family designed for IoT applications. The purpose of the gateway is to bridge the gap between IQRF DPA devices in the field and the Cloud in the easiest way. The gateway is optimized for IQRF DPA networks to manage and control complex environments. The gateway comes with Linux operating system with preinstalled custom software services. The IQ Home gateway is ready to use. All you need to do is to setup our cloud parameters in the gateway and bond IQRF DPA nodes via IQRF IDE.

Ready to use gateway to connect IQRF networks to the Internet.

  • Easy to create IoT sensor networks
  • Easy to integrate with IQRF based sensors
  • RTC on board in case of power outage
  • Protected EEPROM and Flash storage (eeRAID and eMMC RAID)
  • Enhanced reliability feautres
  • IQRF IDE UDP communication support
  • MQTT support
  • JSON messages
  • Automated periodical data collection
  • Automatic DPA timing management
  • Remotely configurable and accessible
RF Specifiaction
IQRF - DPA
DCTR-76D(A)
4.02D
3.02
Low Power (STD on special request)
868 MHz (916 MHz on special request)
8 mW
External
Local display and control
LED (RX/TX)
LED (STAT/ACT)
Environmental conditions
-20 °C to +70 °C
-20 °C to +70 °C
0 % to 85 %
Electrical specification
DC 9V-16V ( power supply not included )
2.5 W (typical)
Mechanical and enclosure specification
107mm(W) x 63mm(D) x 32mm(H)
DIN Rail mountable
150 g
Gray
IP20

There are no reviews for this product.

Write a review

Please login or register to review
Documentation
Gateway
Document Version Format Date
Gateway Family Datasheet [GW-IND-01] 1.0.0 PDFHTML 2018-05-24
Product Briefs
Document Version Format Date
Gateway Brief [GW-IND-01] 1.0.0 PDF 2019-04-09
